ELTEK PRODUCTS

Eltek is a world leader in high-efficiency power electronics and energy conversion. As a global corporation, Eltek has customers in more than 100 countries across a variety of industries including telecom, rail and infrastructure, power generation, power distribution and solar energy.

Eltec Flatpack2 HE Rectifier

Since setting the new standard for rectifier efficiency, the Flatpack2 HE family is now available in a variety of voltages and power ratings, all with superior efficiency up to 96.5%.

With more than 4 billion in-field operating hours and a proven cumulative field MTBF of more than 1,9 million hours, Flatpack 2 HE is the only HE (High Efficiency) rectifier with a proven track

Features:

High Efficiency (up to 96.5 %) even at low load
Proven reliability (MTBF 2,5 million hours)
High Power Density
Application flexibility, 2 - 192 kW
Efficiency Upgrade Kits
Live Upgrade
Accepts DC input (DC/DC Converter
Global Compliance (CE, UL, NEBS)
Patented High Efficiency Technology

Eltec Flatpack2 DC Power Systems

Eltek Valere’s Flatpack2 line consists of a range of versatile, scalable, and highly-configurable systems tailored to individual needs and requirements. Use of established components— including the efficient and reliable Flatpack2 rectifier, the robust Smartpack controller, and remarkably flexible distribution—make for optimal system design and cost-effective deployment.

Features:

Power output options range from 150A to 1200A
Scalable from 2RU to 10RU in height (single distribution)
Low-cost, reliable solutions with standardized components
Module communication via CAN bus
NEBS certified
Optional Flatpack DC-DC converters and shelves
Optional AC junction box for larger systems

Rectifiers and Shelves:

Surge and short circuit protection
TemperSurge and short circuit protection
Status LEDs on each rectifier
Autonomous, active current sharing between rectifiers
Typical rectifier power factor >0.99 at 50% load or more
Low input current distortion (THD)
Individual and dual AC feed options for each shelf

Controller:

USB port and PowerSuite software for computer interface
Web/SNMP model with Ethernet port for network interface
Optional slave controller with additional alarm contacts for larger systems
Advanced battery monitoring and control features

Distribution:

Configurable 1RU distribution shelf for 150A systems
Configurable three-bus breaker panel available with either 20 or 24 breaker positions (19” or 23” width, respectively)
LVD options
Rear-access bulk battery landings
Emergency power-off (EPO) feature for larger systems
Additional 23” distribution panel option for larger systems
